ottoman adopts the design of wide heavy gauge links and built-in
articulating elevated mid-ottoman. Profile shape designed for
safety and appearance without pinch points. Articulating designs
allows use of wider & higher mid-ottoman for elimination of
entrapment areas and for leg support.
The customer has several
options as to how to activate the mechanism. There are cable
style, outside handle style and inside handle style. Easy
operation. Customer can choose to use handle or lever activation
to open the mechanism and the color of the handle or lever.
Slight footrest pressure will allow closing the ottoman.
The system uses
direct drive with double locks. The direct drive with double
over-centre locks enables maximum synchronization of side
positive locking of both sides. Square drive tube connects to
and controls both left and right sides. Ottoman is locked closed
on both sides.
design. The adoption of the flatter links and wider base
mounting points enables greater bending resistance and greater
stability and strength. It improves weight capacity and
durability. The mechanism base width is closer to seat width
while maintaining sufficient clearance between links to
eliminate possibility of interference.
The system uses
the extended life rivet joints design. All rivet joints have
either acetal or bronze rivet bushing and acetal spacers to
eliminate any steel to steel contact. No metal to metal noises
when links contact nylon stop pins.
on wood frame design. The wood frames designed for the rocker
recliner, motorized lift are all interchangeable.
Specification of the
recliners: -1-2-3..... can be custom-made accordingly.
It is exchangeable with
